SJTD Single Head Hinge Boring Machine Model Z-1C

Product successfully added to the Quote List

The SJTD Single Head Hinge Boring Machine Model Z-1C is designed for precise and efficient drilling of hinge holes in woodworking applications, featuring a robust motor and user-friendly operation.

The SJTD Single Head Hinge Boring Machine Model Z-1C is an essential tool for woodworking professionals focused on cabinet and furniture manufacturing. This machine ensures accurate and clean hinge hole drilling, enhancing the quality and efficiency of your production process. Key specifications include:

Specification	Details
Model	Z-1C
Working Table Size	550 mm × 710 mm
Number of Boring Units	1 Unit
Motor Power	1.1 kW / Single Phase
Maximum Drilling Diameter	Ø35 mm
Maximum Drilling Depth	60 mm
Working Voltage	220V / Single Phase
Overall Machine Size	1000 mm × 700 mm × 1550 mm
Machine Weight	150 kg

This machine is equipped with a standard hinge boring head and requires a boring bit (not included). Its compact design and powerful motor make it suitable for various woodworking shops aiming to improve precision and productivity.
