SJTD Auto Bevel 35-Degree Edge Banding Machine Model SJTD-355HC

Product successfully added to the Quote List

The SJTD Auto Bevel 35-Degree Edge Banding Machine SJTD-355HC delivers precision and efficiency in edge banding tasks with advanced touch-screen control and robust trimming and grooving capabilities.

The SJTD Auto Bevel 35-Degree Edge Banding Machine Model SJTD-355HC is designed for professionals seeking top-tier precision and efficiency in edge banding. Equipped with a touch-screen control panel and specialized components, this machine ensures smooth and accurate operation for bevel edge banding tasks.

Specification	Details
Model	SJTD-355HC
Control Panel	Touch Screen
Minimum Panel Length	250 mm
Minimum Panel Width	150 mm
Panel Thickness (Bevel)	14–25 mm
Edging Thickness	0.4–3 mm
Edging Grooving	3–23 mm
Bevel Trimming Unit	380V / 4 kW / 3,000 RPM (35°)
Edge Grooving Unit	0.35 kW
Single Gluing Unit	0.25 kW
End Cutting Unit	0.37 kW × 2 Units
Fine Trimming Unit	0.75 kW × 2 Units
Scraping Units	2 Units
Buffing Units	0.37 kW × 2 Units
Feeding Power	1.5 kW
Feeding Speed	0–12 m/min
Working Pressure	0.6–0.8 MPA
Working Voltage	380V / 50Hz / 3 Phase
