SJTD Precision Sliding Table Saw Model TDe32

Product successfully added to the Quote List

The SJTD Precision Sliding Table Saw Model TDe32 is engineered for accurate and efficient cutting of various wood-based materials, featuring a robust motor and precise angle adjustments to enhance woodworking productivity.

The SJTD Precision Sliding Table Saw Model TDe32 is designed to meet the diverse needs of woodworking professionals. Key specifications include:

Specification	Details
Model	TDe32
Dimension of Sliding Table	3200 × 390 mm
Max. Cutting Length	3200 mm
Saw Blade Diameter	Ø300 mm
Max. Height of Cut at 90°	80 mm
Max. Height of Cut at 45°	55 mm
Main Saw Speed	4000/5000 rpm
Main Saw Spindle Diameter	Ø30 mm
Tilting Saw Blade	0–45°
Main Saw Motor	5.5 kW (7.5 HP) / 415V
Scoring Saw Motor	1.1 kW (1 HP) / 415V
Scoring Saw Blade Diameter	Ø120 mm
Speed of Scoring Saw	9000 rpm
Scoring Saw Spindle Diameter	Ø20 mm
Overall Dimensions (L×W×H)	3400 × 2600 × 1000 mm

This machine is suitable for processing various wood-based panels, including density boards, shaving boards, ABS panels, PVC panels, organic glass plates, and solid wood materials. The inclusion of an Italy Saw Blade and an SJTD Single Bag Dust Collector (Model: MF9022, 3HP/415V) ensures clean and precise operations.
